PAHT-CF

Bambu PAHT-CF — Low-Moisture, High-Strength Nylon-CF

Carbon-fiber reinforced • Stable in humidity • Industrial strength

Overview

Bambu PAHT-CF is a carbon-fiber reinforced PA12 engineered for strong, dimensionally stable parts—even in humid environments. Compared to standard PA-CF, it absorbs less moisture, maintains stiffness when wet, and delivers noticeably stronger Z-layer bonding. Ideal for fixtures, jigs, brackets, molds, and end-use functional parts.

Why choose PAHT-CF

• Low moisture absorption for stable dimensions
• Strong Z-layer adhesion to resist delamination
• High tensile strength and stiffness for load-bearing parts
• Performs well at elevated temperatures
• AMS compatible

Recommended print settings (starting points)

• Drying: 80 °C × 8–12 h (keep < 20 % RH while printing)
• Nozzle: 260–290 °C
• Bed: 80–100 °C (use Magigoo PA)
• Speed: < 100 mm/s
• Printer: Enclosed required

Hardware & build surfaces

• Nozzle: Hardened steel 0.6 mm recommended (0.4 / 0.8 mm OK)
• Plates: High-Temp Plate or Engineering Plate
• Not recommended: Cool Plate, stainless nozzles, 0.2 mm nozzles

Notes & tips

• Always dry thoroughly before printing and after storage
• Use Magigoo PA to improve adhesion and protect the plate
• Remove supports shortly after printing to avoid moisture-related sticking
• Store sealed with desiccant between prints

What’s in the box

• Bambu PAHT-CF filament spool (1.75 mm ± 0.03 mm)
• Desiccant

Local advantages (Convoy-Westcan • Winnipeg)

• Same-day or next-business-day dispatch when in stock
• Free local courier on eligible filament orders over $50
• In-store pickup available

Policy snapshot

Filament is final sale. Approved returns on other items must be brand new and unopened; restocking fees and non-refundable shipping may apply.
